Burgu Delme Makinesi
Created with Pixso.

Customized Auger Drilling Rig, Auger Drilling Rig, Rotary Drilling Rig Single-Flute Straight Auger Bit (Toothed) For construction in clay layers, highly weathered layers, and gravel layers

Customized Auger Drilling Rig, Auger Drilling Rig, Rotary Drilling Rig Single-Flute Straight Auger Bit (Toothed) For construction in clay layers, highly weathered layers, and gravel layers

Marka Adı: WeSeW
Model Numarası: RG-717
MOQ: 1 adet
fiyat: Price Negotiation
Ödeme Şartları: T/T, Western Union
Tedarik Yeteneği: Ayda 1000000 adet
Detay Bilgi
Menşe yeri:
Çin
Sertifika:
CE,UL
Dönüş Yönü:
Saat yönünde/saat yönünün tersine
Vida Tipi:
Helikoid veya kesit
kuvvet:
Yüksek çekme mukavemeti
Uygulanabilir Endüstriler:
Üretim Tesisi, Enerji ve Madencilik
Kullanım:
Konveyör
Çalışma Modu:
Manuel veya Otomatik
Eğim Açısı:
0-45 derece
Özellikler:
Esnek tasarım, temizlenmesi kolay
Ambalaj bilgileri:
Tahta sandık
Yetenek temini:
Ayda 1000000 adet
Vurgulamak:

single-flute straight auger bit

,

auger drilling rig for clay

,

rotary drilling rig with toothed bit

Ürün Tanımı
Customized Auger Drilling Rig - Single-Flute Straight Auger Bit (Toothed)
Professional rotary drilling rig auger bit designed for efficient construction in clay layers, highly weathered layers, and gravel layers.
Product Specifications
Warranty: 2 Years
Quality Assurance: Video outgoing-inspection & Machinery Test Report Provided
Applicable Layers: Clay, high-weathered layer, gravel, etc.
Drilling Diameter: 600-2000 mm
Spiral Height: 1500 mm
Weight: Customized as requested
Bottom Type: Double bottom and double cut, Single bottom and double cut
Key Advantage: High Performance
Straight Auger Design Features
  • Straight type design optimized for efficient soil carrying capacity
  • Double cutter configuration ensures uniform force distribution and prevents hole inclination
  • Dual spiral design facilitates soil transport; single spiral configuration ideal for cohesive soil dumping
  • Versatile application across various geological layers including clay, weathered formations, and gravel
Note: All measurements in millimeters (mm); weight in kilograms (kg)
Technical Specifications Table
Pile Dia. (mm) Spiral HIT. (mm) Spiral Pitch (mm) Spiral THK. (mm) Spiral OD. (mm) Teeth No. Weight (kg)
φ6001500600+40030+205506550
φ8001500600+40030+207509800
φ9001550600+50030+2085010850
φ10001500600+60030+2095011900
φ12001500600+60030+301150131250
φ15001500600+60030+301450161750
φ16001500600+60030+301550171900
φ18001500600+60035+301750212600
φ20001500600+60035+301950223050
Product Images
